| H. Height | 27.1 in |
|---|---|
| H1. Height, steering rod (lowered) | 32.3 in |
| H2. Height, steering rod (raised) | 48.0 in |
| L. Length | 59.4 in |
| L1. Length | 30.0 in |
| W. Basic plate width | 23.6 in |
| Masses | |
| Basic mass | 567 lbs |
|---|---|
| Operating mass (CE) | 573 lbs |
| Traction | |
| Speed | mph |
| Max. gradeability | 32 % |
| Max. working speed | 92 fpm |
| Engine | |
| Manufacturer/Model | Hatz 1D 90 |
| Emissions according to | non EPA |
| Rated power | 13.8 hp |
| Rated power @ | 2,600 rpm |
| Type | Air cooled diesel |
| Number of cylinders | 1 |
| Fuel consumption /h, avg. | 0.6 gal |
| Fuel tank capacity | 2.6 gal |
