| A. Wheelbase | 109 in |
|---|---|
| B. Width | 81 in |
| H1. Height, with ROPS/cab | 116 in |
| H2. Height, w/o ROPS/cab | 87 in |
| K. Ground clearance | 10.2 in |
| L. Length | 144 in |
| R. Turning radius, outside | 220 in |
| W. Width, wheels | 69 in |
| Masses | |
| Operating mass (incl. ROPS) | 12,200 lbs |
|---|---|
| Operating mass (incl. Cab) | 12,900 lbs |
| Mass with max. ballast | 26,700 lbs |
| Operating mass (incl. Canopy) | 11,905 lbs |
| Traction | |
| Transmission | Hydrostatic, direct drive motors at rear tires |
| Speed low | mph |
| Speed high | mph |
| Max. theoretical gradeability | 30 % |
| Speed range | 0-10 mph |
| Engine | |
| Manufacturer/Model | Cummins QSF 2.8 (Stage IIIB/Tier 4final) |
| Rated power, SAE J1995 | 55 kW (74 hp ) @ 2200 U/Min. |
| Type | Water cooled turbo Diesel |
| Fuel tank capacity | 34 gal |
| Electrical system | 12 V |
| Alternative Engine | |
| Manufacturer/Model | Cummins QSB 2.8 (Stage IIIA/Tier 3) |
| Rated power, SAE J1995 | 55 kW (74 hp ) @ 2,200 rpm |
| Type | Water cooled turbo Diesel |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement. Axial piston motors with constant displacement. |
| Steering | Gear pump with constant displacem. |
| Service brake | Hydrost. braking on drive wheels (rear) |
| Parking/Emergency brake | Failsafe multidisc brake in rear axle. |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Pneumatische Walzen | 4700381534 | SMV (SLOW MOVING VEHICLE) SIGN |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Pneumatische Walzen | 4812317436 | CP1200 Tier 4 s/n 10000510x0B004536- | ||
| Pneumatische Walzen | 4812325016 | CP1200 Tier 3 s/n 10000500xxBoo4535 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Pneumatische Walzen | 4812317435 | CP1200 Tier 4 s/n 10000510x0B004536- | ||
| Pneumatische Walzen | 4812317435 | CP1200 Tier 3 s/n 10000500xxBoo4535 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Pneumatische Walzen | 4812317433 | CP1200 Tier 4 s/n 10000510x0B004536- | ||
| Pneumatische Walzen | 4812317433 | CP1200 Tier 3 s/n 10000500xxBoo4535 |
Standard
Arm rest, Backup alarm, Battery switch, Cocoa mats, Documentation (Manuals - one set), Emergency stop, Fuel level display, Horn, Hour meter, Hydraulic check points, Hydraulic oil lever indicator, Interloc system, Key master and start, Lifting and tiedown eyes, Mirrors (process view), Mirrors (traffic view), Neutral start arrangement, Parking brake, Pressurized sprinkler system, Rotating beacon, Seat with suspension, Sliding and swiveling operator unit, Speedometer, Sprinkler system, Sprinkler timer, Standard Platform, Tachometer display, Towing eyelet (rear), Warning – Air cleaner, Warning – Brake, Warning – Clogged hydraulic oil filter, Warning – Engine temperature, Warning – Engine oil pressure, Warning – Hydraulic fluid temperature, Warning – Low charge, Warning – Low fuel level, Working lights LED (front/rear)
Optional
Flexible ballast option: 8 steel ballast (7,720 lb/front) or 12 steel ballast (11,690 lb/front & rear), Air On the Run system, Asphalt temperature meter, Biologically degradable hydraulic oil, Canopy or ROPS/FOPS or Cab incl. ACC, Driving lights (RH or LH), Dyn@link, Dyn@link advanced, Emulsion tank, Fire extinguisher, First aid box, Heat covers for wheels, Michelin Tires, Radio & MP3 player (Cab), Rotating beacon (LED), Rotating beacon (Ignition Control/LED), Seat belts 3” (ROPS or Cab), Seat luxury (ROPS or Cab), Single scrapers, Slow Moving Vehicle sign, Spare tyre, Sprinkler pump (back up), Tool set, Towing eyelet (front), Vandal cover (Canopy or ROPS/FOPS), Water tank lockable, Working lights (night LED)
