| A. Axle track | |
|---|---|
| A. Wheelbase | 2.24 m |
| B1. Width, max. | 3.25 m |
| B2. Width, standard | 2.55 m |
| B3. Width, wheel track | 2.05 m |
| C1. Track width | |
| H1. Height, max. | 3.90 m |
| H2. Height, transport | 3.10 m |
| H3. Height | 0.49 m |
| L1. Length | 6.10 m |
| L3. Length, hopper | 2.12 m |
| W. Width, wheels | 0.30 m |
Vario speed details here
| Masses | |
| Weight | t |
|---|---|
| Weight (incl. standard screed) | 18 t |
| Traction | |
| Maximum paving speed | 1,800 m/s |
| Transport speed | 5.6 m/s |
| Engine | |
| Manufacturer/Model | Cummins QSB6.7-C173 |
| Emissions according to | Stage IIIA/IV (Tier 3/4f) |
| Rated power, SAE J1995 | 129 kW @ 2200 rpm |
| Electrical system | 24 V |
| Fuel tank capacity | 315 l |
| Rated power | hp |
| Rated power | |
| Rated power, SAE J1995 | |
| Conveyor | |
| Conveyor type | Dual bar feeder |
| Conveyor control | The independent conveyor with proportional control |
| Conveyor width | 2x 580 mm |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812027736 | |||
| Large pavers | 4812027736 | 500 mm |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812028516 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812035552 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812229393 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812016661 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812018438 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812018439 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812035553 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812035551 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4812046969 | Tier 3 | ||
| Large pavers | 4812012384 | Tier 4i | ||
| Large pavers | 4812012936 | Tier 4F |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| Large pavers | 4700691229 | Tier 3 | ||
| Large pavers | 4812043983 | Tier 3 Including oil | ||
| Large pavers | 4812012378 | Tier 4i | ||
| Large pavers | 4812012382 | Tier 4i Including oil | ||
| Large pavers | 4812012939 | Tier 4F |
