| A. Wheelbase | 1715 mm |
|---|---|
| B. Width | 1310 mm |
| C. Curb clearance | 550 mm |
| D. Drum diameter | 682 mm |
| H1. Height, with ROPS/cab | 2640 mm |
| H2. Height, w/o ROPS/cab | 1755 mm |
| K. Ground clearance | 175 mm |
| L. Length | 2395 mm |
| O1. Overhang, right | 40 mm |
| O2. Overhang, left | 40 mm |
| R1. Turning radius, outside | 3800 mm |
| R2. Turning radius, inside | 2600 mm |
| S. Drum shell thickness | 13 mm |
| W. Drum width | 1200 mm |
| α. Steering angle | ±30° |
A tool to monitor and control their machine fleet efficiently and conveniently.
| Masses | |
| Max. operating mass | 2710 kg |
|---|---|
| Operating mass (incl. ROPS) | 2600 kg |
| Module mass (front/rear) | 1260 kg/ 1340 kg |
| Traction | |
| Speed range | 0-10 km/h |
| Vertical oscillation | ±10° |
| Max. theoretical gradeability | 43 % |
| Engine | |
| Manufacturer/Model | Kubota D1703-M-DI-E4B (T4f) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 18.5 kW (25 hp ) @ 2200 rpm |
| Fuel tank capacity | 50 l |
| Alternative Engine | |
| Manufacturer/Model | |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement. Radial piston motors (2) with constant displacement. |
| Vibration | Gear pump/motors with constant displacement. |
| Steering | Gear pump with constant displacem. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/ Emergency brake |
Failsafe multidisc brake in both drums. |
| {phrase:compaction_oscillation} | |
| Oscillation frequency | Hz |
| Type of fluid | Volume | Additional info | |
|---|---|---|---|
| Dynapac Gear Oil 300 | 5 liters | Every 2000 hours or yearly 5 liter can PN 4812161883 20 liter can PN 4812161884 209 liter drum PN 4812161885 |
|
| Type of fluid | Volume | Additional info | |
|---|---|---|---|
| Dynapac Engine Oil 200 | 6 liters | Change oil every 250 hours 5 liter can PN 4812161855 20 liter can PN 4812161856 209 liter drum PN 4812161857 |
|
| Type of fluid | Volume | Additional info | |
|---|---|---|---|
| Dynapac Roller Grease | 0,4 kg cartridge PN 4812030096 |
|
| Type of fluid | Volume | Additional info | |
|---|---|---|---|
| Dynapac Hydraulic 300 | 40 liters | Change oil every 2000 hours (yearly) 5 liter can PN 4812161867 20 liter can PN 4812161868 209 liter drum PN 4812161869 |
|
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812115247 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700938893 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812115152 | DUAL F/R CONTROL |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700938909 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700938914 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812156268 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812156288 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812156266 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812156265 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4812156288 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700938887 |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700940594 | ||
| COMPACTION | Double drum vibratory rollers | 4812161288 | 50 pieces. | |
| COMPACTION | Double drum vibratory rollers | 4812161289 | 100 pieces. | |
| COMPACTION | Double drum vibratory rollers | 4812161290 | 200 pieces. |
| Category | Subcategory | P/N | Additional info | |
|---|---|---|---|---|
| COMPACTION | Double drum vibratory rollers | 4700938575 |
Optional
3” seatbelt, Biodegradable hydraulic fluid, Cert. Fire protection (SBF 127), Decal risk location (GOST), Driving lights (right and left handed). Dual forward/reverse control, Fire extinguisher, Flow divider, Foot rest, Hearing protectors, Licence plate light, Rear view mirror (traffic view), Rotating beacon (ignition controlled), Service kit 50/500/1000H, Side direction lights (driving lights required), Slide lux seat, Slow moving vehicle sign, Special color (one or two), Spring loaded scrapers, Tool set, Towing eyelet, Water tank cover (lockable)
